This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ20X100-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10
The AirTAC Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 90 to 100 mm. This model is discontinued — the direct replacement is the MBLJ20X100-10.
- BoreØ20 mm
- Stroke100 mm
- Adjust window90–100 mm
- Port sizeG1/8
- Rod threadM8×1.25
- StatusDiscontinued → MBLJ20X100-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10
The AirTAC MALJ20X100-10 is a discontinued double-acting, double-rod mini cylinder with a 20mm bore and a 100mm stroke. It features a rear adjustable stop that trims up to 10mm, giving a usable end-position window of 90-100mm. The direct replacement is the MBLJ20X100-10.
This SKU has no magnet (-S omitted), so it cannot accept a position sensor. The MALJ uses a fixed rubber bumper and threaded covers, whereas the MBLJ upgrade features a riveted rolling-packed body. The adjuster is a travel stop, not a lock; it sets the end position but will not hold a load without live air pressure.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10 Technical Specifications
| Model | Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ20X100-10 |
| Bore size | Ø20 mm |
| Stroke | 100 mm |
| Adjustable window | 90 – 100 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ20X100-10 carries the same ratings.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | — |
| Max (@1.0 MPa) | 27 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ20X100-10 matches these values.
Model Code: Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×100 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 90–100 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10 Is Used
PCB drilling depth stop
Dial the rear screw to set a precise 95mm reach on a PCB drilling fixture, using the 90-100mm window to prevent drill breakthrough without adding external spacers.
Light-duty pick-and-place
Fine-tune the 100mm extension on a small electronic component pick-and-place machine, using the 20mm bore's compact footprint and 132N pull force to lift parts.
Replacing the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10 with MBLJ20X100-10
Replace the MALJ20X100-10 directly with the MBLJ20X100-10, matching the 20mm bore, 100mm stroke, 10mm adjust code, G1/8 port, and PT thread. Mounting is FA or LB only (no back cover or SDB). Since this SKU lacks a magnet, no sensor fits; upgrading to the MBLJ with an -S code changes the switch family from CS1-M/DS1-M to CMSG/DMSG/EMSG. Remember the adjuster is a stop, not a lock.
Upgrade checklist
- ✓ Order the MBLJ20X100-10 (same bore/stroke/adjust)
- ✓ Same 90–100 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ20X100-10 instead of this discontinued model.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X100-10 FAQ
Yes, the MALJ20X100-10 is discontinued. The direct replacement is the MBLJ20X100-10, which matches the 20mm bore, 100mm stroke, 10mm adjust code, force, and G1/8 port. The MBLJ upgrades the body to a riveted rolling-packed design from the original threaded covers.
The usable stroke window is 90-100mm (100mm stroke minus 10mm adjust code). The adjuster is a travel stop, not a lock, and this no-magnet SKU cannot take a sensor.
