Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-40
2、Front/rear end caps feature threaded connection design;
3、Piston sealing adopts specialized bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
4、Front end incorporates self-lubricating bearing guides for enhanced lubrication and directional stability;
5、Multiple rear mounting configurations enable flexible cylinder installation;
6、Available with various cylinder sizes and compatible mounting accessories for customized configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: MALJ20
AirTAC MALJ20X75-40 Adjustable Miniature Cylinder Specifications
- Model: MALJ20X75-40
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20mm
- Stroke: 75mm (adjustable via external screw)
- Operating pressure: 0.15–0.8 MPa
- Medium: Clean compressed air (lubricated or non-lubricated)
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable air cushion at both ends
- Mounting style: Standard (no built-in mounts, requires brackets)
- Port size: M5 (Rc1/8 optional)
- Piston speed: 50–800 mm/s
- Weight: 0.36 kg
- Dimensions: 130mm(L) × 20mm(Bore W) × 20mm(H) (body only)
- Full extended length: 205mm (including rod)
- Rod thread: M6×1.0 external thread
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54
Ultra-compact cylinder with external stroke adjustment capability, featuring a dual-cushion design for precise end-position control. The anodized aluminum construction ensures corrosion resistance, while the through-rod design allows for position sensing integration. Requires 5μm filtered air for optimal performance.
- Precision clamping in PCB assembly robots
- Valve actuation in medical diagnostic equipment
- Part positioning in semiconductor wafer handlers
- Packaging machine stopper mechanisms
- Automated test equipment sample tray positioning
Installation tip:
Stroke adjustment must be performed with cylinder depressurized.
For repeated accuracy, limit adjustment to 70% of maximum stroke
and apply silicone grease to adjustment screw quarterly.
- 360° rotatable mounting points for flexible orientation
- Transparent end caps for visual position confirmation
- Low-friction piston design (≤0.15 dynamic friction coefficient)
- Compatible with vacuum applications (0.8 MPa reverse pressure)
| Property | Property Value |
|---|---|
| sku | MALJ20X75-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 75mm |
