Airtac MALJ20 Adjustable Mini Cylinder MALJ20X75-50
2、Front/rear end caps feature threaded connection design;
3、Piston sealing adopts specialized bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
4、Front end incorporates self-lubricating bearing guides for enhanced lubrication and directional stability;
5、Multiple rear mounting configurations enable flexible cylinder installation;
6、Available with various cylinder sizes and compatible mounting accessories for customized configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: MALJ20
AirTAC MALJ20X75-50 Adjustable Miniature Cylinder Specifications
- Model: MALJ20X75-50
- Bore size: 20mm
- Stroke: 75mm
- Adjustable stroke range: ±2mm (via external screw)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (axial mounting holes)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR/PU (temperature & wear resistant)
- Weight: ~450g (without accessories)
- Dimensions: 132mm(L) × 20mm(Bore W) × 20mm(Rod DIA)
- Repeat positioning accuracy: ±0.5mm
- Max theoretical thrust: 31.4N @0.5MPa
- Protection rating: IP54 (standard)
Ultra-compact pneumatic cylinder with precision stroke adjustment capability, featuring a space-saving design optimized for confined installations. The dual-cushion structure minimizes end-impact noise while maintaining positioning stability. Integrated mounting slots allow direct integration with linear guides or sensor systems. Requires lubrication-free operation with filtered air (5-50μm).
- PCB handling robots in electronics assembly
- Precision valve actuation in analytical instruments
- Cartesian coordinate pick-and-place systems
- Medical device component positioning
- Semiconductor wafer processing equipment
Installation note:
For optimal performance, align within 0.2mm parallel tolerance during mounting.
Apply thread lock to adjustment screws after calibration. Lubricate rod every 500km
stroke travel using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | MALJ20X75-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 75mm |
