This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ20X80-10, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10
The AirTAC Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 10 mm, giving a usable end-position window from 70 to 80 mm. This model is discontinued — the direct replacement is the MBLJ20X80-10.
- BoreØ20 mm
- Stroke80 mm
- Adjust window70–80 mm
- Port sizeG1/8
- Rod threadM8×1.25
- StatusDiscontinued → MBLJ20X80-10
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10
The AirTAC MALJ20X80-10 is a discontinued double-acting mini cylinder with a 10 mm rear travel stop, giving a usable extension window of 70-80 mm. The direct replacement is the MBLJ20X80-10, matching the 20 mm bore, 80 mm stroke, G1/8 port and 10 mm adjust code.
This SKU has no magnet and cannot accept a position sensor. The rear adjuster is a travel stop, not a lock, so it cannot hold a load without live air. The fixed rubber bumper softens end impact. Upgrading to the MBLJ changes the threaded covers to a riveted rolling-packed body.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10 Technical Specifications
| Model | Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ20X80-10 |
| Bore size | Ø20 mm |
| Stroke | 80 mm |
| Adjustable window | 70 – 80 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 300 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ20X80-10 carries the same ratings.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 132 N | 132 N |
| 0.7 MPa | 185 N | — |
| Max (@1.0 MPa) | 27 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ20X80-10 matches these values.
Model Code: Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 20 | Bore size in mm (20/25/32/40). |
| ×80 | Nominal stroke length in mm. |
| -10 | Adjustable amount: trim the end to a 70–80 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10 Is Used
Dispenser Nozzle Height
Fine-tunes a 72 mm drop for an adhesive dispensing nozzle on a packaging line, trimming the 10 mm rear stop to prevent the tip from crashing into the carton base.
Light-Part Ejector
Pushes small plastic caps out of a mold cavity at a 78 mm stroke, relying on the fixed rubber bumper to soften the ejection impact without damaging the parts.
Replacing the Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10 with MBLJ20X80-10
To replace this MALJ20X80-10, order the MBLJ20X80-10. Confirm the 20 mm bore, 80 mm stroke, 10 mm adjust code, PT G1/8 port, M8x1.25 rod thread and FA/LB mounting. This unit has no -S magnet, so no sensor is needed, but note the MBLJ uses CMSG/DMSG/EMSG switches if you ever add one. The adjuster sets end position but does not lock the load.
If sizing either way, stepping down to a non-adjustable MAL16 drops the 0.5 MPa push force to about 124 N, while stepping up to a MAL25 raises it to 245 N. For any stroke over 300 mm on these mini bodies, watch rod bending from side loads.
Upgrade checklist
- ✓ Order the MBLJ20X80-10 (same bore/stroke/adjust)
- ✓ Same 70–80 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ20X80-10 instead of this discontinued model.
Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-10 FAQ
Yes, the MALJ20X80-10 is discontinued. The direct replacement is the MBLJ20X80-10, which matches the 20 mm bore, 80 mm stroke, 10 mm adjust code, G1/8 port and FA/LB mounting. The MBLJ upgrades the threaded covers to a riveted rolling-packed body.
The usable stroke window is 70-80 mm via the 10 mm rear adjuster. The adjuster is a travel stop, not a lock.
