Airtac MALJ20 Adjustable Mini Cylinder MALJ20X80-20
2、Front/rear end caps feature threaded connection design;
3、Piston sealing adopts specialized bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
4、Front end incorporates self-lubricating bearing guides for enhanced lubrication and directional stability;
5、Multiple rear mounting configurations enable flexible cylinder installation;
6、Available with various cylinder sizes and compatible mounting accessories for customized configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: MALJ20
AirTAC MALJ20X80-20 Adjustable Mini Cylinder Specifications
- Model: MALJ20X80-20
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: Ø20mm (±0.1mm tolerance)
- Stroke: 80mm (adjustable ±2mm)
- Operating pressure: 0.05-1.0 MPa
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Cushion type: External adjustable rubber buffer
- Mounting: Basic foot mounting (MF1) with 4xM4 threaded holes
- Temperature range: -10℃ to 70℃ (NBR seals)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Weight: 0.65kg (without accessories)
- Dimensions: 130mm(L) × 40mm(W) × 60mm(H)
- Max speed: 500mm/s (with cushion engaged)
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact cylinder featuring precision stroke adjustment through external locking nuts, designed for confined spaces requiring millimeter-level positioning accuracy. The dual anti-rotation design maintains piston orientation during operation. Integrated shock absorption reduces end-impact noise to below 70dB.
- PCB handling robots in electronics manufacturing
- Precision dosing mechanisms in pharmaceutical packaging
- Micro-positioning in optical lens assembly
- Semiconductor wafer transfer systems
- Automated test equipment probe positioning
Installation tip:
For vertical mounting applications, install locknuts on both adjustment screws to prevent
unintended stroke changes. Maintain 0.5mm minimum clearance between cushion nuts and end caps.
| Property | Property Value |
|---|---|
| sku | MALJ20X80-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 80 mm |
