Airtac MALJ25 Adjustable Mini Air Cylinder MALJ25X25-10
2. Front/rear end covers feature threaded connections for secure assembly and maintenance;
3. Specially designed bi-directional piston seal structure with compact design and integrated oil reservoir functionality;
4. Front end incorporates self-lubricating bearings for smooth guiding and low friction operation;
5. Multiple rear mounting configurations (base, pivot, flange) for flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for customized pneumatic system integration.
Category: Adjustable Cylinders , Brand: Airtac , Series: MALJ25
AirTAC MALJ25X25-10 Adjustable Miniature Cylinder Specifications
- Model: MALJ25X25-10
- Type: Double-acting adjustable stroke mini cylinder
- Bore size: Ø25mm (ISO 6432 standard)
- Stroke: 25mm (adjustable ±2mm via mechanical stopper)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Rubber buffer with adjustable end position damping
- Mounting styles: Front flange (MF1), rear flange (MF2), or axial clevis (MC1)
- Port size: M5×0.8 (standard) or PT1/8 (optional)
- Temperature range: -20℃ to +80℃
- Seal material: Nitrile rubber (NBR) with wear-resistant piston ring
- Max speed: 500mm/s (optimal range 50-300mm/s)
- Weight: 0.25kg (without accessories)
- Dimensions: 70mm(L) × 25mm(Ø) × 36mm(H) (at mid-stroke)
- Rod thread: M10×1.25 external thread (ISO 12240-1)
Ultra-compact pneumatic cylinder featuring precision-ground stainless steel rod (Cr coating) and anodized aluminum barrel. The dual-cushion design minimizes end-impact noise below 65dB(A) while allowing 0.5 million cycle durability. Integrated mounting slots enable tool-free position adjustment with ±2mm micro-adjustment capability. Optional magnetic piston version (MALJ25X25-10/M) available for position sensing.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms for CNC tool changers
- Medical device actuation systems
- Automated test equipment positioners
- Food packaging line pusher mechanisms
- Semiconductor wafer cassette elevators
Installation note:
Lubricate with ISO VG32 pneumatic oil before initial use.
For vertical mounting, install exhaust mist lubricator (AML-02 series recommended).
Maintain 0.3mm minimum clearance between rod end and load during alignment.
| Property | Property Value |
|---|---|
| sku | MALJ25X25-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <25 mm> |
