Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-10
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X75-10 Adjustable Miniature Cylinder Specifications
- Model: MALJJ32X75-10 (Full designation: MALJ32X75-10)
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 75mm (adjustable via external screw mechanism)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer at both ends
- Mounting style: Foot-mounted (Standard MF1)
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (G1/8 adapter optional)
- Cylinder tube material: Hard anodized aluminum alloy
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 680g ±5% (without accessories)
- Dimensions:
- Extended length: 165mm
- Retracted length: 90mm
- Body width: 42mm
- Mounting height: 32mm
- Max theoretical force: 247N @ 0.7MPa
- Rod thread: M10x1.25 (external)
Ultra-compact linear actuator featuring external stroke adjustment with ±3mm fine-tuning capability. The dual chrome-plated piston rod and integrated shock absorbers enable precise positioning in repetitive motion applications. Unique anti-rotation design maintains alignment during vertical installations. Requires ISO 8573-1 class 3 lubricated air (ISO VG32 recommended).
- PCB handling robots in electronics assembly
- Precision clamping fixtures for CNC machining
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer systems
- Automated optical inspection (AOI) equipment
Installation note:
For optimal performance, limit lateral load to ≤15% of maximum thrust.
Adjust cushioning screws clockwise to increase damping force.
Lubricate guide shafts every 500,000 cycles using silicone-free grease.
| Property | Property Value |
|---|---|
| sku | MALJ32X75-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 75mm |
