Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-20
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X75-20 Adjustable Miniature Cylinder Specifications
- Model: MALJJ32X75-20 (Full designation: MALJ32X75-20)
- Type: Double-acting adjustable cushion cylinder
- Bore size: 32mm
- Stroke: 75mm (±0.5mm tolerance)
- Adjustment range: 0-20mm (external cushion needle valve)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 adapter optional)
- Cushion type: External adjustable rubber bumper
- Mounting style: Basic foot mount (ISO 15552 accessory compatible)
- Piston material: Anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr equivalent ≥3μm)
- Seal material: NBR (Nitrile rubber)
- Weight: 480g ±2% (without accessories)
- Dimensions:
- Length: 153mm (retracted) / 228mm (extended)
- Width: 45mm (mounting foot span)
- Height: 44mm (body diameter)
- Max theoretical force: 80.4N @0.5MPa (push/pull)
- Air consumption: 6.03L/min @0.5MPa (double stroke)
Compact ISO-compliant pneumatic cylinder featuring external cushion adjustment for precise end-position deceleration control. The MALJ32 series combines a space-saving design (20% smaller than standard cylinders) with dual anti-rotation guides for enhanced lateral stability. Optional auto switch grooves (M9/M12) allow sensor integration for position feedback.
- Precision workpiece clamping in CNC jigs
- Sorting gate actuators in packaging lines
- Micro-positioning in semiconductor handling
- Medical device assembly automation
- Robotic end-effector tool changers
Installation note:
Adjust cushion screws in ¼ increments while pressurized. Lubricate with ISO VG32 turbine oil if operating below -10℃.
Maximum side load: 15N. Avoid direct impact forces exceeding 3J.
| Property | Property Value |
|---|---|
| sku | MALJ32X75-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 75mm |
