This model is discontinued
AirTAC has phased out the MALJ series. You can still order this code here: we ship the direct replacement MBLJ32X75-75, with the same bore, stroke, output force, port and mounting, so it fits the same application. The MBLJ replacement upgrades to a riveted rolling-packed body and CMSG / DMSG / EMSG sensors (the MAL used CS1-M / DS1-M).
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75
The AirTAC Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75 is a double-acting aluminum mini cylinder with a rear adjustable-stroke stopper: you can trim up to 75 mm, giving a usable end-position window from 0 to 75 mm. This model is discontinued — the direct replacement is the MBLJ32X75-75.
- BoreØ32 mm
- Stroke75 mm
- Adjust window0–75 mm
- Port sizeG1/8
- Rod threadM10×1.25
- StatusDiscontinued → MBLJ32X75-75
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75
The AirTAC MALJ32X75-75 adjustable-stroke mini cylinder is discontinued. The direct replacement is the MBLJ32X75-75, matching the 32mm bore, 75mm stroke, G1/8 port, and 82kgf max force. This double-acting double-rod unit trims up to 75mm at the rear screw, yielding a usable 0-75mm end-position window for dialing in exact reach without external stops.
The rear adjuster is a travel stop, not a lock, so it cannot hold a load without live air. This SKU lacks the -S magnet and cannot take a position sensor. The original threaded covers and CS1-M sensors upgrade to a riveted body and CMSG/DMSG/EMSG switches on the MBLJ.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75 Technical Specifications
| Model | Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75 |
|---|---|
| Series | MALJ adjustable-stroke mini cylinder (discontinued) |
| Replacement | MBLJ32X75-75 |
| Bore size | Ø32 mm |
| Stroke | 75 mm |
| Adjustable window | 0 – 75 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.1 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed rubber bumper |
| Max standard stroke | Up to 500 mm |
The rear adjuster is a travel stop, not a lock — it sets the end position but does not hold the load without live air. No back-cover code and no SDB on adjustable-stroke. The MBLJ32X75-75 carries the same ratings.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
MALJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod MAL push of the same bore. The MBLJ32X75-75 matches these values.
Model Code: Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75
| MALJ | Adjustable-stroke aluminum mini cylinder, double acting (discontinued). |
|---|---|
| 32 | Bore size in mm (20/25/32/40). |
| ×75 | Nominal stroke length in mm. |
| -75 | Adjustable amount: trim the end to a 0–75 mm window. |
| S | Optional magnet for a CS1-M / DS1-M sensor (MBLJ uses CMSG/DMSG/EMSG). |
Replacement: MALJ → MBLJ. No back-cover (CA/U/CM) and no SDB. Mounting: FA / LB.
Where the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75 Is Used
Dispenser Nozzle Height
Sets a precise lower travel limit for a glue dispensing head, trimming the 75mm stroke to prevent nozzle crash on varying substrate heights.
Leather Skiving Press
Adjusts the stroke stop to regulate blade penetration thickness, relying on the fixed rubber bumper to soften the end impact during rapid cycling.
Replacing the Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75 with MBLJ32X75-75
To replace the MALJ32X75-75, order the MBLJ32X75-75. Confirm the 32mm bore, 75mm stroke, 75mm adjust code, G1/8 PT port, M10x1.25 rod thread, and FA/LB mounting (no back cover or SDB). The adjuster sets the end position but does not lock the load. Since this SKU lacks the -S magnet, it cannot accept a sensor.
Upgrade checklist
- ✓ Order the MBLJ32X75-75 (same bore/stroke/adjust)
- ✓ Same 0–75 mm adjustable window
- ✓ Adjuster is a stop, not a lock
- ✓ No back cover / SDB — plan an FA/LB mount
- ✓ Sensor: swap CS1-M/DS1-M → CMSG/DMSG/EMSG
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.1 – 1.0 MPa operating pressure.
- check The rear adjuster sets the end position — it is not a load lock.
- check No back-cover / SDB on adjustable-stroke — use FA / LB.
- check Front/rear covers are threaded — not for field disassembly.
- check For new builds, specify the MBLJ32X75-75 instead of this discontinued model.
Airtac MALJ32 Adjustable Mini Cylinder MALJ32X75-75 FAQ
Yes, the MALJ32X75-75 is discontinued. The direct replacement is the MBLJ32X75-75, which matches the 32mm bore, 75mm stroke, 75mm adjust code, G1/8 port, and FA/LB mounting. The MBLJ upgrades the body to a riveted rolling-packed design and uses CMSG/DMSG/EMSG sensors if needed.
The 75mm adjuster is a travel stop that lets you trim the end position anywhere in a 0-75mm usable window. It does not hold the load without live air.
