Airtac MALJ32 Adjustable Mini Cylinder MALJ32X80-50
2. Front/rear end caps adopt threaded connection structure for secure assembly;
3. Piston seal utilizes special bidirectional sealing configuration with compact dimensions and oil reservoir function;
4. Integrated self-lubricating bearing in front end cap ensures superior guiding performance and lubrication retention;
5. Multiple rear cushioning configurations enable flexible installation solutions;
6. Comprehensive range of cylinder accessories and mounting brackets available for custom system integration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: MALJ32
AirTAC MALJ32X80-50 Adjustable Miniature Cylinder Technical Details
- Series: MALJ (Mini Adjustable Locking Cylinder)
- Bore size: 32mm
- Stroke: 80mm standard / 50mm adjustable
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Piston rod thread: M10×1.25
- Cushioning: Rubber buffer + adjustable stopper
- Mounting options: Foot-mounted or front flange
- Port size: M5×0.8 (Rc1/8 adaptor included)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.65kg (without accessories)
- Dimensions: 144mm(L) × 32mm(W) × 32mm(H)
- Rod end type: Female thread with locknut
- Protection class: IP54 (standard)
Compact locking cylinder with precision stroke adjustment capability (0-50mm range). Features dual-position memory function through its mechanical locking mechanism, enabling repeatable positioning without continuous air supply. Anodized aluminum construction with chrome-plated piston rod for corrosion resistance.
- Precision jig positioning in PCB assembly
- Clamping mechanisms in semiconductor handlers
- Medical device actuation systems
- Packaging machine stopper adjustment
- Automated test equipment positioning
Installation note:
For optimal performance, maintain 0.5mm clearance between cylinder body and mounting surface.
Lubricate with ISO VG32 hydraulic oil before initial use. Adjust locking nut torque to 1.2-1.5N·m
using calibrated torque wrench.
Critical parameter:
Maximum side load capacity 15N. Exceeding this limit may cause rod bearing deformation.
Use guide mechanisms for lateral force applications.
| Property | Property Value |
|---|---|
| sku | MALJ32X80-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 80 mm |
