Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X10
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X10 Aluminum Miniature Cylinder Technical Details
- Model: MBLCD20X10
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Cushioning: Adjustable air cushion (both ends)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy body, NBR seals
- Mounting type: Basic (no built-in mount) with optional accessories
- Weight: 0.24kg (bare cylinder)
- Dimensions:
- Extended length: 107mm
- Retracted length: 97mm
- Body width: 25mm
- Height with rod: 35mm
- Rod thread: M5x0.8 (external)
- ISO standard: 6432 (miniature cylinder specifications)
Ultra-compact pneumatic cylinder featuring anodized aluminum construction for lightweight durability (60% lighter than standard cylinders). Precision-machined piston rod with chrome plating ensures smooth linear motion. Includes dual adjustable cushioning screws for impact control at stroke ends. Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics manufacturing
- Precision valve actuation in analytical instruments
- Compact clamping mechanisms in CNC tool changers
- Medical device positioning systems
- Food packaging machine pusher mechanisms
Installation guidelines:
Use locknuts (ASN5x8) for rod-end load mounting. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Maximum side load capacity: 3N at mid-stroke.
Recommend using 40μm filtration for optimal seal life.
| Property | Property Value |
|---|---|
| sku | MBLCD20X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
