Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X125S
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X125S Aluminum Mini Cylinder Specifications
- Model: MBLCD20X125S
- Type: Double-acting compact cylinder
- Bore size: 20mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (no built-in mounts) with optional accessories
- Material: Aluminum alloy body (A6063-T5), CRCCU seal rings
- Weight: 0.54 kg (without accessories)
- Dimensions:
- Total length (L): 175mm (stroke + end caps)
- Body width (W): 32mm
- Height (H): 34mm (excluding rod)
- Rod diameter: 8mm
- Piston speed: 50-700 mm/s (optimal range 100-500 mm/s)
- Lubrication: Pre-lubricated (DOP mist compatible)
- Protection rating: IP54 (standard seals)
Ultra-slim profile cylinder with 45% reduced installation space compared to standard models. Features dual anti-rotation guides (rod cannot rotate) and wear-resistant rod bushing. Precision honed tube achieves ≤0.08mm inner diameter tolerance. Suitable for vertical/horizontal mounting in clean environments.
- PCB handling robots in electronics manufacturing
- Precision dosing mechanisms in medical devices
- Label application arms in packaging lines
- Optical lens positioning systems
- Semiconductor wafer transfer units
Installation note:
Requires external guide mechanism for lateral load applications. Use locknuts (M5x0.8) with 0.49-0.98Nm torque for port connections. Lubricate every 3 months under continuous operation.
| Property | Property Value |
|---|---|
| sku | MBLCD20X125S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
