Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X150S
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X150S Aluminum Mini Cylinder Specifications
- Model: MBLCD20X150S
- Type: Single-acting spring return (S-type)
- Bore size: 20mm
- Stroke: 150mm
- Material: Anodized aluminum alloy body (6063-T5)
- Operating pressure: 0.15–0.8 MPa
- Piston speed: 50–700 mm/s (lubricated)
- Port size: M5x0.8 (standard) / 1/8 PT optional
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Mounting: Basic female thread (NF type)
- Weight: 0.62 kg (without accessories)
- Dimensions: 230mm(L) × 34mm(W) × 34mm(H) (retracted)
- Rod end: M6x1 external thread
- Seal material: NBR + PU combination
- Protection rating: IP54 (standard)
- Optional accessories: Magnetic sensor (D-M9N series compatible)
Ultra-compact cylinder optimized for space-constrained automation systems. Features precision honed tube (Ra≤0.4μm) for smooth operation and chrome-plated piston rod (SUJ2 steel) for corrosion resistance. The reduced overall width (34mm) enables dense parallel mounting in multi-axis applications.
- PCB handling robots in electronics manufacturing
- Dispenser actuation in medical device assembly
- Clamping mechanisms in CNC fixture systems
- Conveyor gate controls in packaging lines
- Precision positioning stages in optical equipment
Installation note:
For vertical mounting, use maximum 0.5 MPa pressure to prevent piston rod buckling.
Apply ISO VG32 hydraulic oil for initial lubrication. Allow 1.5mm clearance around cylinder
body for thermal expansion during continuous operation.
| Property | Property Value |
|---|---|
| sku | MBLCD20X150S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 150mm |
