Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X160S
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD Aluminum Miniature Cylinder MBLCD20X160S Specifications
- Model: MBLCD20X160S
- Bore size: 20mm
- Stroke: 160mm
- Construction: Hard-anodized aluminum alloy body
- Operating pressure: 0.1-0.9 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting options: Basic type, front/rear flange, foot-mounted
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: M5×0.8 (standard), optional PT1/8 adaptor
- Rod end thread: M6×1.0
- Protection rating: IP65 (dust-tight & water jet resistant)
- Magnetic switch: Pre-installed (2-wire PNP/NPN configurable)
- Switch voltage: DC12-24V ±10% (standard)
- Weight: 0.62kg ±2%
- Dimensions: 196mm(L) × 50mm(W) × 50mm(H)
Ultra-compact linear actuator featuring precision-ground rod and double O-ring seals for leak-free operation. The hard-coated barrel surface ensures exceptional wear resistance in high-cycle applications (up to 2,000km service life). Integrated magnetizable piston enables position feedback via inductive sensors. Optional shock absorber kits available for high-speed applications (>500mm/s).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Label applicators in pharmaceutical packaging lines
- Valve actuators in cleanroom environments
- Camera module positioning in optical inspection systems
Operational guidance:
Lubricate through air supply (ISO VG32 recommended). Maintain 0.3-0.5mm lateral clearance during alignment.
For vertical mounting, reduce operating pressure by 20% to compensate for gravitational load.
| Property | Property Value |
|---|---|
| sku | MBLCD20X160S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 160mm |
