Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X175S
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X175S Aluminum Miniature Cylinder Specifications
- Model: MBLCD20X175S
- Type: Double-acting mini cylinder
- Bore size: 20mm
- Stroke: 175mm
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (standard), G1/8 optional
- Cushioning: Adjustable pneumatic cushion
- Material: Anodized aluminum alloy body, NBR seals
- Temperature range: -20℃ to 80℃
- Weight: 0.68kg (excluding accessories)
- Dimensions: 225mm(L) × 50mm(W) × 50mm(H) (fully extended)
- Mounting: Standard foot-mounted (ISO 15552 compatible)
- Rod end: Female thread M10x1.25
- Protection rating: IP40 (dust protected)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil)
Ultra-compact cylinder featuring precision honed aluminum barrel and low-friction seals, optimized for high-speed operations (max 1.5m/s). The dual adjustable cushions minimize end-impact noise while maintaining 1.5 million cycle durability. Includes built-in magnet for sensor compatibility.
- PCB handling robots in electronics manufacturing
- Cartesian coordinate sorting systems
- Pharmaceutical blister packaging machines
- Cleanroom wafer transfer mechanisms
- Automated optical inspection (AOI) equipment
Installation note:
Maintain 0.5-1mm clearance between piston rod and load connection to prevent side load.
For vertical mounting, use counterbalance valves. Lubricate every 6 months under normal operation.
- Max thrust: 63N @ 0.63MPa
- Static friction: ≤2.5N
- Air consumption: 9.8cm³/stroke
- Repeat positioning accuracy: ±0.2mm
| Property | Property Value |
|---|---|
| sku | MBLCD20X175S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 175mm |
