Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X200
$41.63
Regular price
$49.13
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLCD20X200
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with AirTAC corporate standards, featuring precision-engineered aluminum round tube barrel construction;
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
Installation note:
Maximum side load 15N. For vertical mounting, use locking nut (ASNU6) to prevent stroke drift.
Lubricate every 3 million cycles under continuous operation.
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X200 Aluminum Mini Cylinder Specifications
- Model: MBLCD20X200
- Type: Double-acting compact cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 200mm (customizable 1-300mm)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (PT1/8 optional)
- Cushion type: Adjustable rubber buffer
- Material: Aluminum alloy barrel / Chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Mounting style: Basic foot mount (ISO 15552 accessory compatibility)
- Weight: 580g ±2% (without accessories)
- Dimensions:
- Total length: 280mm (stroke+132mm)
- Body width: 32mm
- Height with rod: 57mm
Ultra-slim profile cylinder (only 20mm width) with hardened stainless steel guide bushing for precise linear motion. Features anti-rotation mechanism and IP65 protection rating. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
Typical Applications:
- PCB handling robots in electronics assembly
- Lab automation sample positioning stages
- Medical device actuation systems
- Compact packaging machine ejectors
- Semiconductor wafer processing equipment
Installation note:
Maximum side load 15N. For vertical mounting, use locking nut (ASNU6) to prevent stroke drift.
Lubricate every 3 million cycles under continuous operation.
| Property | Property Value |
|---|---|
| sku | MBLCD20X200 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <200mm> |
