Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X225S
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X225S Aluminum Miniature Cylinder Specifications
- Model: MBLCD20X225S
- Type: Double-acting compact cylinder
- Bore size: 20mm
- Stroke: 225mm
- Operating pressure: 0.15–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / optional 1/8 NPT
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Basic foot mounting (ISO 6432 compatible)
- Material: Anodized aluminum barrel, stainless steel piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 0.92kg ±3%
- Dimensions:
- Total length (L): 285mm (stroke + end caps)
- Body diameter: 32mm
- Mounting hole spacing: 40mm
- Rod end thread: M6x1.0
Ultra-compact aluminum cylinder designed for space-constrained automation systems. Features corrosion-resistant construction, low friction seals, and precise stroke control. The anodized surface treatment enhances wear resistance, while the built-in magnetic ring allows position sensing compatibility (sensors sold separately). Requires 40μm filtered air and ISO VG32 hydraulic oil lubrication for optimal performance.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Medical device actuation systems
- Semiconductor wafer handling equipment
- Automated optical inspection (AOI) systems
Installation note:
Maintain proper rod alignment (max angular misalignment <0.5°) and use anti-vibration
mounts in high-cycle applications (>500 cycles/min). For vertical mounting,
install with rod end downward to prevent piston drift.
| Property | Property Value |
|---|---|
| sku | MBLCD20X225S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 225mm |
