Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X25
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X25 Aluminum Miniature Cylinder Specifications
- Model: MBLCD20X25
- Type: Double-acting compact cylinder
- Bore size: 20 mm
- Stroke: 25 mm (±1.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Port thread: PT1/8 (NPT1/8 optional)
- Cushioning: Adjustable rubber buffer
- Mounting style: Basic type (optional foot/rod-end mounts)
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy body, hard anodized finish
- Seal material: NBR (Nitrile rubber)
- Weight: 220 g ±5%
- Dimensions (L×W×H): 98mm × 40mm × 40mm (at mid-stroke)
- Rod thread: M6×1.0 external thread
- Protection rating: IP40 (Dust protected)
- Theoretical force: 63N at 0.5MPa (extend/retract)
Ultra-compact cylinder optimized for space-constrained automation systems. Features precision honed bore for smooth operation and dual adjustable cushions for reduced impact at stroke ends. Corrosion-resistant anodized surface withstands industrial environments. Requires 40μm filtered air and ISO VG32 hydraulic oil lubrication (optional).
- PCB handling robots in electronics assembly
- Dispenser actuation in medical device manufacturing
- Clamping mechanisms in CNC tool changers
- Paper feed systems in compact printers
- Valve switching in beverage vending machines
Installation note:
Maintain 0.5mm minimum alignment tolerance during mounting. Lubricate through air port (2-3 drops of oil weekly in dry conditions). Avoid side loads exceeding 15N. For vertical mounting, use model with magnetic piston (MBLCDM variant).
| Property | Property Value |
|---|---|
| sku | MBLCD20X25 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
