Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X30
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X30 Aluminum Mini Cylinder Specifications
- Model: MBLCD20X30
- Type: Double-acting compact cylinder
- Bore size: 20mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Basic (axial mounting holes)
- Port size: M5x0.8 (standard) with NPT1/8 adaptor option
- Material: Aluminum alloy body (anodized), CRMo steel piston rod
- Seal material: NBR/PU combination
- Weight: 0.45kg (excluding accessories)
- Dimensions:
- Body length: 71mm
- Total extended length: 101mm (71+30mm stroke)
- Width: 28mm (mounting bracket included)
- Height: 28mm
- Max theoretical force: 94N @0.5MPa
- Piston speed: 50–800mm/s
- ISO standard: 6432 (miniature cylinder specifications)
Ultra-compact aluminum cylinder with space-saving design (28% smaller than standard ISO cylinders), featuring corrosion-resistant anodized surface and precision honed bore. The dual anti-rotation design ensures stable linear motion, while the chrome-plated piston rod provides exceptional wear resistance. Requires filtered air with 5-40μm filtration and ISO VG32 hydraulic oil lubrication (optional).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in optical lens production
- Valve actuation in medical analyzers
- Packaging machine ejector systems
- Cleanroom automation equipment
Installation tip:
Maintain 0.5mm minimum clearance between piston rod and guide mechanisms.
For vertical mounting, use counterbalance valves when handling loads over 5kg.
Lubricate every 3 months under normal operating conditions.
| Property | Property Value |
|---|---|
| sku | MBLCD20X30 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
