Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X300S
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X300S Aluminum Mini Cylinder Specifications
- Model: MBLCD20X300S
- Type: Double-acting compact cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 300mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Mounting style: Basic foot/axial (ISO 15552 accessory compatibility)
- Material: Aluminum alloy body (anodized), CR12MoV piston rod
- Seal material: NBR (nitrile rubber) with wear-resistant ring
- Weight: 1.23kg (excluding accessories)
- Dimensions: 403mm(L) × 34mm(W) × 34mm(H) (fully extended)
- Rod thread: M10×1.25 (female)
- Max theoretical force: 283N @0.7MPa
- Speed range: 50–800mm/s (with cushioning)
Ultra-slim profile cylinder optimized for confined spaces, featuring precision-ground rod and corrosion-resistant construction. Integrated buffer adjustment prevents end-impact while maintaining 90%+ efficiency across full stroke. Requires 5μm filtered air with ISO VG32 lubrication (non-lube version available).
- SCARA robot end-effector positioning
- Medical device actuation systems
- Semiconductor wafer handling equipment
- Compact packaging machine pushers
- Automated microscope stage movement
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations,
use rod-down orientation to prevent condensate ingress. Lubricate rod weekly in
high-cycle applications (>500k cycles/year).
| Property | Property Value |
|---|---|
| sku | MBLCD20X300S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 300mm |
