Airtac MBLCD Aluminum Alloy Mini Cylinder MBLCD20X40
2. Riveted aluminum clamshell structure integrates front/rear end caps with aluminum alloy barrel for enhanced connection reliability;
3. Custom-profiled bidirectional piston sealing system delivers compact dimensions with integrated oil reservoir functionality;
4. Multiple rear cover configurations facilitate flexible installation options;
5. Comprehensive range of cylinder specifications and mounting accessories available for diverse industrial applications.
Category: Aluminum Miniature Cylinders | Brand: AirTAC | Series: MBLCD Series
AirTAC MBLCD20X40 Aluminum Mini Cylinder Technical Details
- Model: MBLCD20X40
- Type: Double-acting compact cylinder
- Bore size: 20mm
- Stroke: 40mm (standard), customizable 5-300mm
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard), G1/8 optional
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic front flange (ISO 15552 compatible)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile) with wear-resistant ring
- Protection rating: IP67 (dust/water resistant)
- Weight: 0.38kg (excluding accessories)
- Dimensions: 120mm(L) × 30mm(W) × 30mm(H) (at full extension)
Ultra-compact linear actuator optimized for space-constrained automation systems. Features precision-machined aluminum construction with chrome-plated piston rod (hardness HRC 45-50) and integrated magnetic field for sensor attachment. Requires filtered air (5-50μm) with ISO VG32 lubricant (optional oil-free operation).
- Robotic gripper mechanisms in assembly lines
- Medical device positioning systems
- High-cycle packaging machinery actuators
- Semiconductor wafer handling equipment
- Automated test fixture clamping
Maintenance tip:
Lubricate every 3 million cycles under normal operation. Avoid lateral loading exceeding 15N.
Use rod lock nut (optional MBLN series) for vertical applications.
| Property | Property Value |
|---|---|
| sku | MBLCD20X40 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <40mm> |
