Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-10
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Mini Cylinder MBLCJ20X100-10 Technical Specifications
- Model: MBLCJ20X100-10
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushion type: Adjustable rubber buffers (both ends)
- Mounting style: Front/rear threaded (M10x1.25) with optional foot mounting bracket
- Port size: M5x0.8 (dual ports on both ends)
- Piston rod material: Chrome-plated steel (S45C)
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seals: NBR (standard), optional Fluorocarbon for high temp
- Weight: 0.54kg (with standard accessories)
- Dimensions:
- Extended length: 194mm
- Retracted length: 94mm
- Body width: 34mm
- Mounting height: 20mm
- Max theoretical thrust: 31.4kgf@0.5MPa
- ISO standard: 6432 (25mm series compatible)
Ultra-compact cylinder featuring precision-machined internal guides and dual adjustable cushions for smooth stroke termination. The hexagonal body design allows easy wrench adjustments during installation. Integrated mounting threads enable direct machine integration without brackets. Optional magnetic piston version (suffix -M) available for position sensing.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms in CNC tool changers
- Actuation in medical analyzer instruments
- Small parts ejection systems in micro-molding machines
- Optical lens alignment equipment
Operational note:
For optimal performance, maintain lubrication with ISO VG32 hydraulic oil mist.
Avoid side load exceeding 3N·m. Cushion adjustment requires 2mm hex key (included).
Maximum allowable lateral play: ±0.2mm.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X100-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
