Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-30
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X100-30 Specifications
- Model: MBLCJ20X100-30
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Piston speed: 50–700 mm/s (optimal at 500 mm/s)
- Cushion adjustment range: 0–5mm (external screw adjustment)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Piston rod thread: M6×1.0
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Weight: 0.62kg (excluding accessories)
- Dimensions: 140mm(L) × 24mm(W) × 34mm(H) (retracted state)
- Max lateral load: 15N at midpoint
- ISO standard compliance: ISO 6432, VDMA 24562
- Lubrication: Pre-lubricated (Oil-free operation possible)
Ultra-compact cylinder featuring patented cushion mechanism with 360° adjustable shock absorption. The anodized aluminum body with chromium-plated piston rod ensures corrosion resistance in Class II environments. Integrated mounting threads (M5×0.8 on both ends) enable flexible installation configurations.
- PCB handling robots with limited workspace
- Precision lens positioning in optical equipment
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer mechanisms
- Automated test probe positioning systems
Installation guidelines:
For vertical mounting, use counterbalance valves when holding loads.
Maintain 0.3μm filtration for air supply. Cushion adjustment should be
performed at 80% of maximum operating pressure. Allow 2mm clearance
behind end caps for cushion mechanism activation.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X100-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
