Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-50
$41.63
Regular price
$49.13
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLCJ20X100-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with AIRTAC enterprise standards, featuring an aluminum round tube barrel construction;
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
Installation note:
Adjust cushion screws while observing motion - turn clockwise to increase damping. Lubricate with ISO VG32 hydraulic oil for initial operation. Maintain 1mm minimum clearance around cylinder body for heat dissipation.
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ20X100-50 Adjustable Miniature Cylinder Specifications
- Model: MBLCJ20X100-50
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Adjustment range: 0-50mm via external cushion screws
- Operating pressure: 0.1–0.9 MPa
- Max thrust: 62.8N at 0.5MPa (extend), 53.6N (retract)
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard), G1/8 optional
- Piston speed: 50–700mm/s (optimal range 100–500mm/s)
- Seal material: NBR (standard), optional FKM for high temp
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Weight: 0.52kg (with standard fittings)
- Dimensions:
- Extended length: 220mm (base to rod end)
- Retracted length: 120mm
- Body diameter: 32mm
- Mounting base: 40mm x 20mm
- Protection class: IP54 (standard), IP67 optional
Ultra-compact cylinder featuring dual adjustable pneumatic cushions for precise end-position deceleration. The aluminum alloy construction with hard anodizing ensures corrosion resistance in humid environments. Integrated mounting slots allow direct installation in confined spaces without additional brackets.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping devices for CNC tool changers
- Medical device actuators requiring smooth motion
- Automated test equipment positioners
- Food packaging machine ejectors (food-grade version available)
Installation note:
Adjust cushion screws while observing motion - turn clockwise to increase damping. Lubricate with ISO VG32 hydraulic oil for initial operation. Maintain 1mm minimum clearance around cylinder body for heat dissipation.
Compatible Accessories:
- Mounting brackets: MFH-20 series
- Rod end fittings: MXC2-6
- Position sensors: D-A93 series magnetic switches
| Property | Property Value |
|---|---|
| sku | MBLCJ20X100-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
