Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-50S
$43.49
Regular price
$50.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLCJ20X100-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with AIRTAC enterprise standards, featuring an aluminum round tube barrel construction;
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
Installation tip:
For vertical mounting, reduce operating pressure by 20% to compensate for gravity load.
Use locknuts on adjustment screws after tuning. Lubricate rod with ISO VG32 turbine oil
every 500km of cumulative travel.
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X100-50S Technical Details
- Model Code Breakdown: MBLCJ20X100-50S = 20mm bore × 100mm stroke (50S variant)
- Bore Size: 20mm (precision honed tube)
- Stroke: 100mm (±0.5mm tolerance)
- Operating Pressure: 0.05-1.0 MPa (7-145 psi)
- Cushioning: Adjustable air cushion at both ends
- Port Size: M5x0.8 (standard) or NPT1/8 optional
- Piston Material: Anodized aluminum alloy
- Rod Material: Hard chrome-plated steel
- Seals: NBR (nitrile) standard, optional FKM/Viton for high temp
- Temperature Range: -20℃ to 80℃ (extended to 120℃ with FKM seals)
- Max Speed: 500 mm/s (with cushioning)
- Weight: 480g ±3% (excluding accessories)
- Dimensions (L×W×H):
- Retracted: 136mm × 34mm × 34mm
- Extended: 236mm × 34mm × 34mm
- Mounting: Front flange with 4x M5 threaded holes (ISO 15552 mounting pattern)
- Accessories: Built-in magnet for position sensing (SMCR series sensors compatible)
Ultra-compact cylinder with micro-adjustment capability through integrated stroke adjustment screws (±2mm fine-tuning). Features dual anti-rotation guides for precise linear motion and IP54-rated dust/water resistance. Lubrication-free design with self-compensating wear resistance.
Ideal Applications:
- PCB handling robots requiring micron-level positioning
- Pharmaceutical tablet pressing mechanisms
- Semiconductor wafer clamping systems
- Compact packaging machine ejectors
- Dental chair height adjustment mechanisms
Installation tip:
For vertical mounting, reduce operating pressure by 20% to compensate for gravity load.
Use locknuts on adjustment screws after tuning. Lubricate rod with ISO VG32 turbine oil
every 500km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X100-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
