Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-10
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X125-10 Specifications
- Model: MBLCJ20X125-10
- Type: Double-acting adjustable cushioning cylinder
- Bore size: 20mm
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Piston speed: 50–700 mm/s
- Cushioning type: Adjustable air cushion (both ends)
- Port size: M5x0.8 (dual ports at both ends)
- Rod thread: M6x1.0 external thread
- Material: Aluminum alloy barrel, CR12MoV piston rod
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 360g ±5% (without accessories)
- Dimensions:
- Extended length: 195mm
- Retracted length: 70mm
- Body diameter: 28mm
- Mounting base: 32mm x 32mm
Ultra-compact cylinder featuring precision-machined components and dual adjustable pneumatic cushions for smooth end-stroke deceleration. The anodized barrel provides enhanced corrosion resistance, while the chrome-plated piston rod ensures durability in high-cycle applications. Includes built-in mounting threads and auto switch grooves for sensor integration.
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in optical lens production
- Medical device assembly automation
- Compact packaging machine actuators
- Laboratory sample handling systems
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between cushion screws and end caps during adjustment.
Not recommended for lateral loading exceeding 15N - use guide mechanism for side forces.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
