Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-100S
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Mini Cylinder MBLCJ20X125-100S Specifications
- Model: MBLCJ20X125-100S
- Type: Adjustable stroke compact pneumatic cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (adjustable range: ±5mm via stopper)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber seals (oil-resistant)
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (dual ports)
- Mounting type: Standardized accessory mounting grooves (ISO 6432)
- Weight: 0.65kg (without accessories)
- Dimensions:
- Retracted length: 145mm
- Extended length: 270mm
- Body width: 32mm
- Height with rod: 42mm
Ultra-compact cylinder with micro-adjustment capability, featuring a space-saving design that occupies 30% less installation space than standard cylinders. The double cushioning system minimizes end-impact noise (≤65dB) while maintaining positioning accuracy (±0.5mm repeatability). Integrated mounting slots allow direct attachment of sensors or brackets.
- Precision part insertion in SMT machinery
- Lab automation sample handling systems
- Medical device actuation mechanisms
- Robotic end-effector positioning
- Semiconductor wafer handling equipment
Operation notes:
- Use filtered air (5-40μm) with lubrication (ISO VG32 recommended)
- Maximum piston speed: 500mm/s
- Adjust stopper clockwise/counterclockwise for ±5mm stroke tuning
- Allow 10mm clearance for sensor bracket installation
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
