Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-10S
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X125-10S Technical Details
- Model: MBLCJ20X125-10S
- Series: MBLCJ (Compact Adjustable Stroke)
- Bore size: 20mm
- Stroke: 125mm (adjustable)
- Mounting type: Female rod-end thread (M10×1.25)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Rubber buffer (both ends)
- Port size: M5×0.8 (Rc1/8 adapter included)
- Seal material: NBR (nitrile butadiene rubber)
- Piston rod material: Stainless steel (SUS304)
- Repeat positioning accuracy: ±0.5mm
- Max. piston speed: 500 mm/s
- Weight: 0.35kg (excluding accessories)
- Dimensions: 125mm (stroke length) × 40mm (body width) × 42mm (height)
- Rod thread depth: 8mm (both ends)
Ultra-compact cylinder with stroke adjustment mechanism (10mm minimum adjustment increments) featuring a space-saving design that occupies 30% less volume than standard cylinders. The dual-cushion structure reduces impact noise to below 75dB. Includes anti-rotation guide for precise linear motion, with optional magnetic version (add "-M" suffix) for position sensing.
- PCB component insertion machines
- Medical device assembly stations
- Packaging machine ejector mechanisms
- Semiconductor wafer handling
- Automated test equipment positioning
- Robotic gripper actuation systems
Installation guidelines:
For optimal performance, maintain 0.5-1mm axial clearance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side loads exceeding 15N.
When adjusting stroke, loosen both lock nuts simultaneously using 5mm hex wrench.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
