Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-75
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ Adjustable Miniature Cylinder MBLCJ20X125-75 Technical Details
- Model: MBLCJ20X125-75
- Bore size: 20mm
- Stroke: 125mm (adjustable range: ±3mm)
- Port thread: M5x0.8 (standard), G1/8 optional
- Operating pressure: 0.15-0.8 MPa
- Operating temperature: -20℃ to 80℃
- Piston speed: 50-700 mm/s
- Buffer type: Adjustable pneumatic cushion
- Mounting style: Basic type (accessory brackets available)
- Rod end: Female thread M6x1.0
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 0.58kg (without accessories)
- Dimensions (L×W×H): 225mm × 40mm × 25mm (extended length)
- Installation spacing: 25mm (center-to-center mounting holes)
- Max thrust: 94N @0.6MPa (extending side)
Ultra-compact cylinder featuring a dual-axis adjustable stroke mechanism with ±3mm fine-tuning capability through rotating end caps. The anodized aluminum construction provides corrosion resistance while maintaining lightweight performance. Integrated shock absorption reduces end-impact noise to below 75dB(A). Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms for CNC tool changers
- Micro-assembly systems in medical device manufacturing
- Packaging machine ejector systems
- Automated test equipment probe positioning
Installation recommendation:
For vertical mounting applications exceeding 45° inclination,
use optional guide brackets (MBMX-20) to prevent side load.
Lubricate with ISO VG32 hydraulic oil during initial installation.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-75 |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
