Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X125-75S
2、Integrated riveted aluminum cladding structure ensures reliable connection between end caps and alloy barrel;
3、Compact piston design with specialized bidirectional sealing profile incorporating oil reservoir functionality;
4、Multiple rear cover configurations enhance mounting flexibility;
5、Comprehensive product range with various cylinder sizes and mounting accessories for optimal system integration.
Category: Adjustable Cylinders , Brand: AIRTAC , Series: MBLCJ
AirTAC MBLCJ20X125-75S Adjustable Miniature Cylinder Specifications
- Model: MBLCJ20X125-75S
- Type: Double-acting adjustable cushioning cylinder
- Bore size: 20mm
- Stroke: 125mm (±0.5mm tolerance)
- Adjustable cushion range: 0-75mm (both ends)
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5x0.8 (Rc1/8 optional)
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal type: NBR wear-resistant seals
- Temperature range: -20℃ to 80℃
- Weight: 0.34kg (without accessories)
- Dimensions (retracted): 200mm(L) × 42mm(W) × 42mm(H)
- Mounting style: Standard front flange with 4xM5 threaded holes
- Rod end: Female M6x1 thread
- Cushion adjustment: External screw-type with locknut
Ultra-compact cylinder featuring dual adjustable pneumatic cushions for precise stroke-end deceleration. The hardened aluminum construction provides corrosion resistance while maintaining lightweight performance (30% lighter than standard cylinders). Includes built-in magnet for sensor compatibility. Requires filtered air (5-50μm) with ISO VG32 lubricant recommended.
- PCB handling robots in electronics manufacturing
- Precision dosing mechanisms in medical devices
- Cartesian coordinate pick-and-place systems
- Semiconductor wafer processing equipment
- Compact packaging machine actuators
Installation tip:
For optimal performance, align cushion adjustment screws perpendicular to motion direction.
Lubricate rod every 500km of travel in high-cycle applications. Max side load: 15N.
| Property | Property Value |
|---|---|
| sku | MBLCJ20X125-75S |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
