Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X10-10
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X10-10 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X10-10
- Type: Double-acting adjustable cushioning cylinder
- Bore size: 20mm
- Stroke: 10mm
- Mounting type: Basic type (MF1)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable (both ends)
- Port size: M5x0.8
- Material: Aluminum alloy body (anodized), POM end caps
- Seal material: NBR rubber
- Protection rating: IP40
- Weight: 0.23 kg
- Dimensions:
- Total length (L): 92mm (including rod)
- Body width (W): 30mm
- Height (H): 25mm (excluding mounting hardware)
- Rod diameter: 6mm
Ultra-compact linear actuator with precision stroke control, featuring dual adjustable pneumatic cushions for smooth end-position deceleration. The hard-anodized barrel provides exceptional wear resistance, while the dual sealing system ensures leak-free operation in high-cycle applications. Requires 5μm filtered air and regular lubrication (ISO VG32 recommended).
- Precision positioning in semiconductor handling equipment
- Clamping mechanisms in compact automation cells
- Valve actuation in analytical instruments
- Component ejection systems in micro-molding machines
- Orientation adjustment in optical device assembly
Installation note:
Maximum side load capacity 15N. For vertical mounting,
use anti-rotation accessories (MBLJ-Z series). Lubricate
rod weekly in dusty environments. Avoid axial twisting
during piping connection.
| Property | Property Value |
|---|---|
| sku | MBLJ20X10-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
