Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X10-10S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X10-10S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X10-10S
- Series: MBLJ (Compact Adjustable Aluminum Body)
- Bore size: 20mm
- Stroke: 10mm ±1mm (Adjustable)
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Cushioning: Adjustable rubber bumper (both ends)
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Rod thread: M6x1 (Double-ended)
- Material: Aluminum alloy body, CRMo steel piston rod
- Seal type: NBR seals with wear-resistant ring
- Weight: 280g ±5g
- Dimensions: 76mm(L) × 34mm(W) × 34mm(H) (Retracted position)
- Extended length: 86mm (Max. stroke position)
- Mounting options: Basic type (No pre-mount brackets)
- Protection rating: IP54 (Standard)
Ultra-compact cylinder featuring micrometer-style stroke adjustment (±1mm fine-tuning) through rotating end caps. Precision-machined with hard anodized surface treatment for corrosion resistance. Integrated cushioning system minimizes end-impact noise below 75dB. Compatible with all major brand pneumatic fittings.
- PCB assembly pick-and-place mechanisms
- Semiconductor wafer handling robots
- Precision dispensing equipment
- Medical device actuator systems
- Optical lens positioning stages
- Desktop automation prototypes
Installation note:
Apply silicone-free lubricant (ISO VG32) during assembly. For vertical mounting,
use locknuts on both rod ends to prevent rotation. Maintain 0.5mm minimum
clearance between rod end and load during alignment.
| Property | Property Value |
|---|---|
| sku | MBLJ20X10-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
