Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-10
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-10 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-10
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: Ø20 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (standard) / NPT1/8 (optional)
- Cushion type: Adjustable rubber bumper (both ends)
- Material: Aluminum alloy body, NBR seals
- Piston rod material: Stainless steel (SUS304)
- Mounting type: Basic foot mounting (ISO 6432 standard)
- Weight: 0.82 kg
- Dimensions: 154mm(L) × 40mm(W) × 40mm(H)
- Max speed: 500 mm/s
- Lubrication: Pre-lubricated (Dry operation allowed)
Ultra-compact cylinder featuring 360° adjustable stroke positioning via dual locking nuts. The anodized aluminum construction provides corrosion resistance for harsh environments. Integrated cushioning mechanism minimizes end-impact noise (adjustable over 3mm range). Compatible with ISO 6432 mounting accessories.
- Precision clamping in PCB assembly robots
- Actuation in medical device auto-loaders
- Part ejection systems in compact injection molding machines
- Position control for semiconductor wafer handlers
- Automated test equipment positioners
Installation note:
Apply thread lock (medium strength) to adjustment nuts during installation.
Maintain 0.5-1mm clearance between rod end and load during alignment.
Recommended air filtration: 5μm with auto-drain.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
