Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-100
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-100 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-100
- Type: Adjustable stroke double-acting cylinder
- Bore size: 20mm
- Stroke: 100mm (adjustable via built-in stopper)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 31.4kgf at 0.5MPa (extend)
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting type: Standard female thread (M5x0.8 mounting holes)
- Port size: M5 (Rc1/8/NPT1/8 optional)
- Material: Aluminum alloy body, NBR seals
- Weight: 340g ±5% (without accessories)
- Dimensions:
- Length: 175mm (fully retracted)
- Width: 32mm (body diameter)
- Height: 42mm (including mounting lugs)
- Rod end: M6x1.0 external thread
- Lubrication: Pre-lubricated (Grease-free operation)
- ISO standard: Compliant with ISO 6432
Ultra-compact cylinder featuring a unique adjustable stroke mechanism with ±2mm fine-tuning capability through its rotary end lock. The hard anodized surface provides enhanced wear resistance in dusty environments. Integrated mounting grooves allow direct sensor attachment for position feedback.
- Precision clamping in PCB assembly robots
- Valve actuation in beverage dispensing machines
- Paper feed mechanisms in office automation equipment
- Position adjustment in semiconductor wafer handlers
- Tool positioning in dental CNC machines
Installation note:
For optimal performance, limit lateral load to ≤15% of maximum thrust.
Use locknuts (not included) when implementing vertical mounting configurations.
Stroke adjustment requires 8mm hex wrench (supplied with unit).
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
