Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-100S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ Adjustable Aluminum Miniature Cylinder MBLJ20X100-100S Specifications
- Model: MBLJ20X100-100S
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting type: Basic (axial mounting threads M5×0.8)
- Material: Aluminum alloy body, NBR seals
- Weight: 0.82 kg
- Dimensions: 200mm(L) × 34mm(W) × 34mm(H)
- Port size: M5×0.8 (standard)
- Lubrication: Non-lube operation (pre-lubricated)
- Protection rating: IP54
Ultra-compact aluminum cylinder with precision-adjustable cushioning mechanism, designed for space-constrained automation systems. Features corrosion-resistant anodized surface and dual anti-rotation guide slots for stable linear motion. Optional magnetic piston version available (add "-M" suffix to model).
- PCB handling robots in electronics manufacturing
- Precision clamping devices for CNC tooling
- Medical analyzer sample tray positioning
- Textile machinery thread control systems
- Semiconductor wafer transfer mechanisms
Installation note:
Ensure proper alignment of guide slots during mounting. Adjust cushion screws
gradually (1/4 turn increments) while testing under operational speed. Maintain
0.3-0.5mm clearance between rod end and load during alignment.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
