Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-10S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-10S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-10S
- Bore size: 20mm
- Stroke: 100mm
- Operation: Double-acting
- Adjustment type: External screw-type cushioning (both ends)
- Working pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Port size: M5x0.8 (Rc1/8 optional)
- Mounting type: Basic (no flange) with 2x mounting holes
- Rod thread: M6x1.0
- Material: Anodized aluminum body, CRMo steel piston rod
- Seal material: NBR/PU combination
- Weight: 0.68 kg (with standard accessories)
- Dimensions: 178mm(L) x 32mm(W) x 32mm(H) (fully retracted)
- Cushion stroke: 10mm (adjustable)
- Protection rating: IP54 (standard)
Ultra-compact cylinder featuring precision-machined aluminum construction with dual adjustable air cushions for smooth end-of-stroke deceleration. The corrosion-resistant design incorporates a hard-anodized barrel and chrome-plated rod, optimized for high-cycle automation tasks. Includes built-in magnet for sensor compatibility.
- PCB handling robots in electronics assembly
- Pharmaceutical blister packaging machines
- Lens positioning systems in optical equipment
- Automated test probe actuation
- Cleanroom material handling systems
Installation note:
Adjust cushion screws incrementally (max 3 full turns) while monitoring deceleration.
Use locknut after adjustment. Lubricate through air port (ISO VG32 recommended).
Avoid side loads exceeding 3N·m.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
