Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-20
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-20 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-20
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm
- Stroke: 100mm (±0.5mm tolerance)
- Rod diameter: 8mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Cushion type: Adjustable air cushion (both ends)
- Mounting type: Front flange with axial mounting holes
- Port size: G1/8 (M5 optional)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions:
- Extended length: 176mm
- Retracted length: 76mm
- Body width: 34mm
- Height (with mounting flange): 50mm
- Protection class: IP40
- Lubrication: Pre-lubricated (Oil-free operation possible)
Ultra-compact aluminum cylinder featuring precision-machined components and dual adjustable pneumatic cushions for smooth end-of-stroke deceleration. The anodized surface treatment provides corrosion resistance in humid environments. Integrated mounting flange allows direct installation in confined spaces while maintaining structural rigidity.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms in CNC fixture systems
- Actuation of small valves in medical analyzers
- Material sorting gates in high-speed packaging lines
- Z-axis movement in desktop 3D printers
Operation tip:
For optimal cushioning performance, adjust cushion screws while observing actual stroke movement.
Complete 1/4 turns and allow 2-3 cycles between adjustments. Avoid over-tightening (max torque 0.5N·m).
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
