Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-20S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-20S Adjustable Aluminum Miniature Cylinder Specifications
- Model: MBLJ20X100-20S
- Bore size: 20mm
- Stroke: 100mm (adjustable)
- Mounting type: Front flange with integrated mounting holes + rear dual studs
- Material: Anodized aluminum alloy body, CR12MoV piston rod
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Port size: M5 (1/8")
- Piston rod thread: M6x1 external thread
- Seal material: NBR (nitrile rubber)
- Weight: 0.82kg ±2%
- Dimensions:
- Total length (extended): 200mm
- Body diameter: 32mm
- Mounting flange width: 40mm
- Stroke adjustment range: 90-110mm
Ultra-compact cylinder with dual-position stroke adjustment mechanism, featuring precision-machined aluminum construction for lightweight durability. The built-in shock absorption system reduces end-impact noise to below 70dB. Unique T-slot design allows tool-free stroke adjustment via hex key (included). IP54-rated for dust and splash resistance.
- Robotic gripper mechanisms in electronics assembly
- Precision position control for semiconductor handling
- Compact packaging machine actuators
- Medical device linear motion systems
- Automated optical inspection equipment
Installation tip:
For optimal performance, maintain 0.5-1mm alignment tolerance during mounting.
Lubricate piston rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500,000 cycles/year).
- Loosen both cushion lock nuts using 8mm wrench
- Rotate cushion screws (CW to shorten stroke/CCW to extend)
- Verify stroke with test operation
- Re-tighten lock nuts to 1.2N·m torque
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
