Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-30
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-30 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-30
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20mm
- Stroke: 100mm (±15mm adjustable)
- Adjustment range: 30mm (15mm per side)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushion type: Rubber buffer with adjustable screw
- Mounting style: Basic non-magnetic type (optional foot/flange mounts)
- Material: Aluminum alloy body, CR seals
- Weight: ~0.65kg (without accessories)
- Dimensions:
- Length: 170mm (full extension)
- Body diameter: 32mm
- Rod diameter: 6mm
- Mounting hole spacing: 25mm (front) / 18mm (rear)
Ultra-compact cylinder with mechanical stroke adjustment capability, featuring anodized corrosion-resistant surface. The through-rod design allows external position sensing. Precision honed tube ensures ≤0.5mm positioning repeatability. Includes magnetic piston for sensor compatibility.
- Precision assembly equipment stroke control
- Packaging machine clamping mechanisms
- Medical device positioning systems
- Laboratory automation sample handling
- Semiconductor wafer transfer units
Installation note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Lubricate with ISO VG32 hydraulic oil before first use. Avoid lateral loading >15N.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
