Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-30S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-30S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-30S
- Type: Adjustable stroke double-acting mini cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (adjustable through stroke limiter)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (dual ports at both ends)
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting type: Swivel base with slot adjustment
- Material: Anodized aluminum alloy body, stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.62kg ±2%
- Dimensions (L×W×H): 198mm × 40mm × 40mm (max extended length)
- Rod thread: M6×1.0 external thread
- Piston speed: 50–700mm/s
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact cylinder featuring precision stroke adjustment via rotary limiter mechanism. The hard anodized surface provides wear resistance in dusty environments. Integrated mounting slots allow ±5° angular adjustment during installation. Requires lubrication-free operation with clean compressed air (ISO 8573-1:2010 Class 3.4.2).
- Precision part insertion in SMT pick-and-place machines
- Micro-positioning in semiconductor wafer handling
- Clamping mechanisms in compact jig systems
- Actuation in medical device assembly lines
- Packaging machine gate controls
Installation tip:
For optimal performance, align piston rod within 0.5mm lateral tolerance.
Adjust cushioning screws gradually (1/4 turns) while testing at working speed.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
