Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-40
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-40 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-40
- Type: Double-acting with adjustable cushion (mini series)
- Bore size: Ø20mm
- Stroke: 100mm (±0.5mm tolerance)
- Port size: M5x0.8 (1/8" NPT optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Piston speed: 50–700 mm/s (optimal at 200–500 mm/s)
- Ambient temperature: -20℃ to +80℃
- Buffer adjustment: 20° rotation range (clockwise stiffening)
- Mounting: Foot/Flange (MF-01 series compatible)
- Rod end: M5x0.8 internal thread (external thread adapter available)
- Material: Aluminum alloy body (anodized), CR seals
- Weight: 750g (excluding accessories)
- Dimensions: 180mm(L) × 40mm(W) × 50mm(H) (full extension)
- Rod diameter: Ø10mm (chrome-plated steel)
- Mounting spacing: 40mm (M5x0.8 tapped holes)
- IP rating: IP54 (standard wiper seal)
Ultra-compact cylinder featuring dual adjustable pneumatic cushions for precise end-position control. The lightweight aluminum construction (35% lighter than steel equivalents) combines with corrosion-resistant surface treatment for harsh environments. Integrated mounting slots enable flexible orientation - suitable for vertical/horizontal installations. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Precision lens positioning in optical equipment
- Dental chair adjustments
- Beverage can sorting mechanisms
- 3D printer filament feed systems
Installation tip:
When using in vertical orientation, install with piston rod facing downward to prevent
seal wear from gravitational settling. Allow 2mm clearance around cylinder body for heat
dissipation during high-cycle operations (＞1Hz).
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
