Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-40S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ Adjustable Aluminum Miniature Cylinder MBLJ20X100-40S Specifications
- Model: MBLJ20X100-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø20 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting style: M4x0.7 tapped holes on base
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M6x1.0
- Material: Aluminum alloy body, CR12MoV piston rod
- Seal material: NBR/PU compound seals
- Protection rating: IP54 (standard) / IP67 (optional)
- Weight: 1.2 kg ±3%
- Dimensions: 140mm(L) × 40mm(W) × 40mm(H)
Ultra-compact linear actuator featuring stroke adjustment via mechanical stoppers (±3mm fine-tuning capability). Precision-machined guide bushing ensures smooth operation with ≤0.5mm lateral play. Corrosion-resistant anodized surface treatment withstands industrial washdown environments. Includes built-in magnet for position sensing compatibility.
- PCB handling robots in electronics assembly
- Dispensing nozzle positioning systems
- Medical device actuation mechanisms
- Automated packaging machine grippers
- 3D printer Z-axis compensation units
Installation note:
Apply thread locker (medium strength) on adjustment screws after stroke setting.
Lubricate with ISO VG32 hydraulic oil during maintenance. Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
