Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-50
$31.39
Regular price
$38.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MBLJ20X100-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with AirTAC corporate standards, featuring extruded aluminum round tube construction;
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
Installation tip:
For vertical mounting, reduce operating pressure by 20% to compensate for gravity load.
Lubricate rod weekly in high-cycle applications (>500,000 cycles/month).
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-50 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-50
- Type: Double-acting adjustable cushioning cylinder
- Bore size: 20mm
- Stroke: 100mm
- Rod diameter: 8mm
- Port size: M5×0.8 (dual ports both sides)
- Operating pressure: 0.05–0.8 MPa
- Max theoretical thrust: 126N @0.5MPa
- Piston speed: 50–700mm/s
- Cushion type: Adjustable rubber bumper (both ends)
- Material: Anodized aluminum alloy body, CR seals
- Temperature range: -20℃ to 80℃
- Weight: 0.58kg (excluding accessories)
- Dimensions: 200mm(L) × 34mm(W) × 34mm(H)
- Mounting: Standard ISO 6432 with front flange
- Protection rating: IP54 (standard seals)
Ultra-compact linear actuator with precision-adjustable end cushioning, optimized for space-constrained automation systems. Features dual anti-rotation guide slots and corrosion-resistant construction. Requires 40μm filtered dry air with 1-3 drops/m³ lubricant (ISO VG32 recommended).
Typical Applications:
- PCB handling robots in electronics assembly
- Precision dosing mechanisms in medical devices
- Label applicators in packaging lines
- Cartesian coordinate pick-and-place systems
- Semiconductor wafer processing equipment
Installation tip:
For vertical mounting, reduce operating pressure by 20% to compensate for gravity load.
Lubricate rod weekly in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
