Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-50S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X100-50S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X100-50S
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Operating medium: Dry air (Lubricated air requires oil mist separator)
- Temperature range: -20℃ to 80℃
- Cushion type: External adjustable rubber bumper (both ends)
- Mounting type: Basic style (no built-in mounting brackets)
- Rod end: Female thread M5x0.8 (ISO 3408-1)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR/PU combination
- Weight: 680g ±3% (including standard accessories)
- Dimensions:
- Total length (L): 190mm (stroke 100mm + base length)
- Body diameter (W): 34mm (hexagonal housing)
- Height (H): 48mm (including cushion screws)
- Port size: M5x0.8 (dual ports on both ends)
- Max speed: 500mm/s (with cushion adjustment)
- ISO standard: Compliant with ISO 6432:2015
Ultra-compact pneumatic cylinder featuring external cushion adjustment screws for precise end-position deceleration control. The hexagonal body design allows easy wrench tightening and space-efficient installation. Chrome-plated rod with dual wiper seals ensures dust resistance in ISO 3 cleanliness environments. Requires 5μm filtered air for optimal performance.
- Precision positioning in SMT equipment component handling
- Actuation mechanisms in semiconductor wafer processing tools
- Compact clamping devices for CNC fixture systems
- Automated liquid dispensing systems
- Medical analyzer reagent arm mechanisms
Installation note:
Adjust cushion screws clockwise to increase damping force (1/4 turn increments recommended).
Maintain 0.5-1mm gap between rod end and load during mounting to prevent side force.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
