Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X100-75S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ Adjustable Aluminum Miniature Cylinder MBLJ20X100-75S Specifications
- Model: MBLJ20X100-75S
- Bore size: 20mm
- Stroke: 100mm
- Adjustable stroke range: ±3mm (via external screw)
- Operating pressure: 0.05-0.9 MPa
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: SWL-75S base (swivel base with tapped holes)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR seals
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Daphne AL-2 grease)
- Weight: 0.58kg (including mounting base)
- Dimensions: 178mm(L) × 50mm(W) × 54mm(H)
- Max theoretical thrust: 28.3kgf @0.5MPa
- Air consumption: 3.14L/stroke @0.5MPa
Ultra-compact cylinder featuring position-lockable stroke adjustment mechanism and integrated shock absorption. The SWL-75S mounting base allows ±5° angular adjustment during installation. Optimized for high-speed cycling (up to 5 cycles/sec) with minimal stick-slip effect. Requires 40μm filtered compressed air.
- PCB board clamping in SMT equipment
- Precision part ejection in micro-molding machines
- Lens positioning mechanisms in optical inspection systems
- Medical device component actuation
- Robotic gripper finger control
Installation note:
Locking nut torque should not exceed 0.5N·m during stroke adjustment.
For vertical mounting, install exhaust mist separator when using oil-free air.
| Property | Property Value |
|---|---|
| sku | MBLJ20X100-75S |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
