Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-100
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ Adjustable Aluminum Miniature Cylinder MBLJ20X125-100 Specifications
- Model: MBLJ20X125-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20mm
- Full stroke: 125mm
- Adjustable stroke range: 0-100mm (via external stopper)
- Mounting style: Standard foot mounting with 2x M5 threaded holes
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Rubber buffer + adjustable screw
- Port size: M5x0.8 (standard) with optional NPT1/8 adapters
- Material: Anodized aluminum alloy body, CRMo steel piston rod
- Seal material: High-grade NBR seals
- Weight: 0.75kg (including mounting hardware)
- Dimensions: 200mm(L) × 32mm(W) × 42mm(H) at full extension
- Rod thread: M6x1.0 external thread at piston end
- Max theoretical force: 31.4N at 0.5MPa (push/pull)
Ultra-compact cylinder with micro-adjustment capability, featuring a 360° rotatable stopper mechanism for precise stroke control. The hard-anodized surface provides excellent corrosion resistance in humid environments. Integrated mounting slots allow flexible orientation adjustments during installation.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms in CNC tool changers
- Valve actuation in compact fluid control systems
- Medical device automation requiring ISO Class 4 cleanliness
- Textile machinery thread tension control
Installation note:
Lubricate piston rod with ISO VG32 hydraulic oil before initial use.
For vertical mounting, reduce maximum load by 30%. Allow 0.5mm
clearance around rod for thermal expansion during continuous operation.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
