Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-100S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-100S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X125-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (adjustable via cushion mechanism)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushion type: Adjustable air cushion + rubber buffer
- Mounting style: Adjustable foot-mount (standard)
- Material:
- Barrel: Hard anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 580g ±2% (excluding accessories)
- Dimensions:
- Extended length: 225mm (stroke 125mm)
- Retracted length: 100mm
- Body width: 32mm
- Mounting base height: 10mm
- Rod end: Female thread M6x1.0
- Max speed: 500mm/s
- Protection rating: IP54 (standard wiper design)
Ultra-compact aluminum cylinder featuring a unique dual-cushion system (adjustable air + fixed rubber) for precise end-position control. The anodized surface provides enhanced corrosion resistance, while the through-rod design allows for easy position feedback sensor installation. Requires ISO 8573-1 class 3 or cleaner compressed air.
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC machining
- Labeling machine positioning mechanisms
- Pharmaceutical blister packaging systems
- Semiconductor wafer transfer units
Installation note:
For optimal performance, maintain 0.5-1mm clearance between cushion adjustment screws and stoppers during initial setup. Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
