Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-10S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-10S Adjustable Aluminum Miniature Cylinder Specifications
- Model: MBLJ20X125-10S
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Buffer type: External adjustable rubber cushion (both ends)
- Mounting type: 2x M5 threaded side taps + front flange options
- Material: Aluminum alloy body (A6063-T5), stainless steel piston rod (SUS304)
- Seal material: NBR with grease pre-lube
- Weight: 520g ±3% (without accessories)
- Dimensions: 180mm(L) × 40mm(W) × 40mm(H) (fully extended)
- Rod thread: M10×1.25 male thread
- Max theoretical thrust: 31.4kgf @0.5MPa
- Port size: M5×0.8 (G1/8 adaptor available)
- Lubrication: Non-lube or ISO VG32 turbine oil
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact linear actuator featuring precision-machined aluminum construction and dual adjustable cushioning for smooth end-stroke deceleration. The T-slot mounting design allows 180° rotation flexibility. Integrated wear-resistant guide bushings ensure ≤0.2mm lateral play during operation. Compatible with magnetic sensors (SM/SMF series) for position feedback.
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC tooling
- Pharmaceutical blister packaging machines
- Cleanroom automation systems
- Semiconductor wafer transfer mechanisms
Installation note:
For optimal performance, maintain 0.3-0.5mm alignment tolerance during mounting.
Use locknuts with ≤10N·m torque. Lubricate rod weekly in high-cycle applications (>500k cycles/year).
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
