Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-20S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ Adjustable Aluminum Mini Cylinder MBLJ20X125-20S Specifications
- Model: MBLJ20X125-20S
- Bore size: 20mm
- Stroke: 125mm
- Mounting type: Front adjustable mounting bracket (M4×0.7 screw)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/8 (G1/8 optional)
- Cushion type: Adjustable pneumatic cushion
- Material: Aluminum alloy body, stainless steel piston rod
- Seal material: NBR rubber
- Rod thread: M5×0.8
- Weight: 0.6kg ±3%
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H) (at fully retracted position)
- Operation type: Double-acting
- Max theoretical thrust: 95N @0.63MPa
- Piston speed: 50–700mm/s
Ultra-compact cylinder with 360° adjustable stroke mechanism, featuring a precision-machined aluminum body for lightweight durability (30% lighter than standard cylinders). The dual-cushion design minimizes end-impact noise below 75dB. Includes built-in auto-lubrication grooves compatible with ISO VG32 hydraulic oil.
- PCB handling robots in electronics manufacturing
- Precision clamping in medical device assembly lines
- Label applicators in packaging machinery
- Valve actuators in semiconductor wafer processing
- Conveyor sorting systems with space constraints
Installation tip:
For vertical installations exceeding 45° angle, use the optional counterbalance valve (MBV-02).
Lubricate rod every 500km stroke travel using ISO Class 32 turbine oil. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
