Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-30
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-30 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X125-30
- Bore size: 20mm
- Stroke: 125mm
- Adjustable stroke range: ±30mm (total 60mm adjustment)
- Mounting type: Front/rear threaded (M10x1.25)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable elastic buffer
- Port size: M5x0.8 (dual ports)
- Piston rod thread: M10x1.25
- Material: Aluminum alloy cylinder tube, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.48kg (excluding accessories)
- Dimensions: 180mm(L) × 40mm(W) × 40mm(H) (fully extended)
- Action type: Double-acting
- ISO standard: 6432
- Lubrication: Pre-lubricated (dry operation possible)
Ultra-compact aluminum cylinder with stroke adjustment mechanism, featuring a 360° rotatable mounting base and precision ground piston rod. The dual-cushion design minimizes end-impact noise, while the anti-rotation guide slot ensures stable linear motion. Includes built-in magnetic sensor slots for position detection compatibility.
- Precision clamping in semiconductor handling equipment
- Position adjustment in automated optical inspection (AOI) systems
- Miniature press mechanisms for electronic component assembly
- Packaging machine ejector systems requiring stroke fine-tuning
- Medical device actuation with space constraints
Installation note:
Maximum side load capacity 15N. For optimal performance, maintain 0.3-1.0 MPa operating pressure range.
Use Cushion needle adjustment tool (included) for precise buffering calibration. Avoid exceeding 80% of
theoretical thrust at maximum pressure.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-30 |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
